Virtualizer, Pro dsp2024p. Read online or download PDF. Behringer DSP2024P User Manual Manuals Directory ManualsDir.com - online owner manuals library Search. Behringer.com 2 VIRTUALIZER 3D FX2000 User Manual Thank you In purchasing the BEHRINGER VIRTUALIZER PRO you have acquired an extremely efficient multi-effects processor that offers first class reverberation effects and a. The BEHRINGER VIRTUALIZER PRO is a flexible unit that can be used in various applications. Prior to a presentation of the DSP2024P’s many uses, please note the following remarks on how to set signal levels correctly. Level setting. Take care to set all levels properly on the DSP2024P!
Version 1.1 January 2005
VIRTUALIZER PRO DSP2024P
VIRTUALIZER PRO
High-Performance 24-Bit Multi-Engine Effects Processor
s Conceived and designed by BEHRINGER Germany | DSP2024P | ||||||||
s 71 breathtaking new algorithms, most in true stereo | |||||||||
s Wave-adaptive VIRTUAL ROOM reverb algorithms for ultra-natural reverb and delay | |||||||||
s Awesome modulation, dynamic, psychoacoustic and EQ algorithms | |||||||||
s Innovative amp simulation, distortion and special effects | |||||||||
s 11 effect combinations with selectable serial/parallel configuration | |||||||||
s Up to 7 adjustable parameters plus HI and LO EQ per effect | |||||||||
s High-resolution 24-bit A/D and D/A converters with 64/128-times oversampling | |||||||||
s True stereo processing for realistic channel separation in stereo image | |||||||||
s 24-bit internal signal processing, professional 46 kHz sample rate | |||||||||
s 100 factory presets plus 100 user memory locations | |||||||||
s Extensive MIDI implementation | |||||||||
s Precise 8-segment LED level meters | |||||||||
s Internal power supply for professional applications | |||||||||
s Servo-balanced XLR and 1/4' TRS inputs and outputs | |||||||||
VIRTUALIZER PRO DSP2024P
8. SPECIFICATIONS
ANALOG INPUTS | |
Connectors | XLR and 1/4' TRS |
Type | RF filtered, servo-balanced input stage |
Impedance | 80 kΩ balanced |
Nominal Operating Level | -10 dBV or +4 dBu (selectable) |
Max. Input Level | +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level |
ANALOG OUTPUTS | |
Connectors | XLR and 1/4' TRS |
Type | Electronically servo-balanced output stage |
Impedance | 80 Ω balanced |
Max. Output Level | +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level |
SYSTEM SPECIFICATIONS | |
Bandwidth | 20 Hz to 20 kHz, +/- 3 dB |
SNR | 91 dB, unweighted, 20 Hz to 20 kHz |
THD | 0.018 % typ. @ +4 dBu, 1 kHz, 0 dBu input, gain 1 |
Crosstalk | < -76 dB |
MIDI INTERFACE | |
Type | 5-pin DIN-socket IN / OUT / THRU |
DIGITAL PROCESSING | |
Converters | 24-bit Sigma-Delta, 64/128-times oversampling |
Sampling Rate | 46.875 kHz |
DISPLAY | |
Type | 4-digit 14 segment alpha-numeric LED-Display |
POWER SUPPLY | |
Voltage | USA/Canada |
120 V~, 60 Hz Download games for android apk. Jan 25, 2017 Play Klondike Solitaire with this simple game. Highly customizable: There are 5 different looking card sets in this game, 12 different card backgrounds and 6 different background colours. | |
Europe/U.K./Australia | |
230 V~, 50 Hz | |
Japan | |
100 V~, 50 - 60 Hz | |
General export model | |
120/230 V~, 50 - 60 Hz | |
Fuse | 100 - 120 V~: T 200 mA H 250 V |
200 - 240 V~: T 100 mA L 250 V | |
Power Consumption | 15 Watts max. |
Mains Connection | Standard IEC receptacle |
PHYSICAL | |
Dimensions (H x W x D) | 1 3/4' x 19' x 8' (44 mm x 482,6 mm x 204,4 mm) |
Net Weight | approx. 4 1/2 lbs (2 kg) |
Shipping Weight | approx. 6 2/3 lbs (3 kg) |
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
VIRTUALIZER PRO DSP2024P
Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of printing. The names of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks of their respective owners. Their use neither constitutes a claim of the trademarks by BEHRINGER® nor affiliation of the trademark owners with BEHRINGER®. BEHRINGER® accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colours and specification may vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not agents of BEHRINGER® and have absolutely no authority to bind BEHRINGER® by any express or implied undertaking or representation. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER® is a registered trademark.
ALL RIGHTS RESERVED. © 2005 BEHRINGER Spezielle Studiotechnik GmbH,
Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.
Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
26
VIRTUALIZER PRO DSP2024P
3.7
Restoring the factory presets
To restore the DSP2024P to its preset factory state, press and hold the STORE and PRESET keys while
switching on the unit. “INIT” appears in the DISPLAY and counting takes place from R 1 to R 100.
000e
This overwrites all changes you have made and restores the factory presets!
4. APPLICATIONS
Behringer Virtualizer Pro Dsp2024p Manuale Italiano
The BEHRINGER VIRTUALIZER PRO is a flexible unit that can be used in various applications. Prior to a
presentation of the DSP2024P’s many uses, please note the following remarks on how to set signal levels
correctly.
4.1
Level setting
Take care to set all levels properly on the DSP2024P! Low levels deteriorate the dynamics of the music signal,
which results in a poor, weak and noisy sound. On the other hand, excess levels overdriving the converters in
the VIRTUALIZER PRO should also be avoided. Digital distortion is (unlike its analog counterpart) extremely
unpleasant, since it does not occur gradually but abruptly.
Please use the OPERATING LEVEL switch and the input level meter of the DSP2024P. Make sure that the
Clip LEDs flickers only rarely. Ensure that they never light up all the time!
4.2
Using the VIRTUALIZER PRO in the aux bus
Behringer Virtualizer Pro Dsp2024p Manual Pdf
Using the DSP2024P in the aux bus lets you feed signals from one, several or all channels of your console into
the VIRTUALIZER PRO. When miking a drum kit, for example, you can use the aux controls to adjust the
reverberation independently for each channel. Thus, you are able to assign a strong reverb to the snare rather
than the toms. Cabling the VIRTUALIZER PRO in the aux bus should be carried out as follows:
Fig. 4.1: Wiring aux busses
Behringer Dsp2024p Multi Effects Processor
Connect both inputs of the VIRTUALIZER PRO to the aux send outputs of your mixer. The DSP2024P’s output
socket is connected to the aux return inputs of your mixer. If you want to operate the BEHRINGER VIRTUALIZER
PRO in mono, connect one of its channels (left or right) to an aux bus. As a matter of principle, effects
processors should always be connected to post fader aux busses.
